Walls For Installation
If you have any questions about installation, please contact us via email: admin@flowzoe.eu
Drywall with studs¹
Max/Max Pro/Slim/Row/MF-01/MF-02 can be installed directly onto drywall with wooden stud center spacing of 30/60 cm. Among these, Slim requires only one stud for installation, so there is no special requirement for stud center spacing.
Drywall with studs²
If the wooden studs center spacing is not 30/60 cm, two additional horizontal wooden boards should be fixed onto the studs first, and then Max/Max Pro/Row/MF-01/MF-02/Wallfly should be mounted onto two boards. The length of the wood board should be greater than the product's lateral width, with a width of 20 cm and a thickness of 2 cm.
Concrete wall
Every product can be installed directly onto a concrete wall.
Solid brick wall
Every product can be installed directly onto a solid brick wall. For hollow block walls, please use toggle bolts (not included in the package) instead.
For Drywall Installation
If installed on drywall, make sure the mounting area is reinforced with studs/a suitable support structure to ensure a safe and secure installation.
Installation Manual
